Description
Adventure is what you make it – and the Kathmandu Hybrid ONE from CUBE will make any pedal-powered adventure better. With its 800Wh PowerTube battery and Bosch CX drive there's up to 85 Nm of pedalling assistance at your disposal. Combined with the easy shifting and wide range of Shimano's Cues 1x10 gears, it's more than enough to take on any route with ease. The Suntour air suspension fork, suspension seatpost and adjustable stem are all there to make even long days in the saddle enjoyable. Strong, dependable Shimano hydraulic disc brakes give you safe stopping in all weathers. And a full complement of accessories, including lights and mudguards to accompany our Integrated Carrier 3.0, means you're ready for anything.
The CUBE Kathmandu Hybrid's design is classically elegant – familiar, even – but it's stuffed full of innovation and clever touches. The neatly housed Bosch CX drive and 800Wh PowerTube battery are just the start. Efficient Comfort Geometry is designed around a 100mm travel suspension fork, for better control even when the going gets rough. Integrated cables complement the frame's clean lines, while a UDH dropout is tough, versatile and future-proof. And, of course, there's an integrated chain guard mount and our tough, sturdy and exceptionally neat Integrated Carrier 3.0, so you can carry everything you need for your adventures.
Specifications
FRAME
Material: Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Boost148, UDH™, Fully Integrated Battery, IC 3.0, Advanced Internal Cable Routing, Integrated Seatclamp
SUSPENSION
Fork: SR Suntour NX1-32 LO Air, Tapered, 15x110mm, 100mm
Headset: ACROS AZF-1035, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), HIC
E-BIKE SYSTEM
Drive Unit: Bosch Drive Unit Performance Line CX max. 100Nm (BDU38), 32kph
Battery: Bosch PowerTube 800
Charger: Bosch 2A
Display: Bosch Purion 200 with Integrated Display
COCKPIT
Stem: CUBE Comfort Stem Pro, 31.8mm, Adjustable
Handlebar: CUBE Comfort Trail Bar, 700mm
Grips: ACID Travel Comfort
DRIVETRAIN & BRAKES
Rear Derailleur: Shimano Cues RD-U6000-GS, 10-Speed
Shifters: Shimano Cues SL-U6000, Rapidfire-Plus
Brake System: Shimano BR-MT200, Hydr. Disc Brake (180/180)
Crankset: ACID MTB Hybrid Pro, 40T
Cassette: Shimano Cues CS-LG300, 11-48T
Chain: KMC eGlide
WHEELS
Wheelset: ACID Pro 25, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
Tyres: Schwalbe Motion Big Apple, PerfL, 55-622
FINISHING KIT
Saddle: ACID Sequence 180
Seat Post: CUBE Suspension Seatpost HD, 31.6mm
Pedals: ACID PP Trekking
WEIGHT & MISC
Weight: 27,5 kg
Maximum System Weight: 140 kg
Maximum Rider Weight: 110 kg
Colour: metallicgrey´n´grey
