Description
Discover your adventurous side, and see where it leads you. The Reaction Hybrid Performance takes the smooth power assistance – up to 75 Nm – of Bosch's Performance motor and adds easy-to-use Shimano Cues 9-speed gears and a 600Wh battery. Powerful Shimano hydraulic disc brakes and grippy Schwalbe Smart Sam 2.6in tyres give you reliable stopping power in any weather. And a suspension fork with 120mm travel (100mm for smaller frame sizes), comfortable saddle and lock-on grips ensure you're comfortable for the long haul. Follow your curiosity...
The versatile and rugged Reaction Hybrid Performance is built around Bosch's quiet, powerful Performance motor with 75 Nm torque. It's Bosch Smart System-equipped and fitted with a 600Wh battery for miles of pedal assistance. There's a clever flat mount for an optional kickstand and a mounting point for a multi-tool under the top tube. The Internal Cable Routing plus an innovative speed sensor setup flatter the frame's clean lines, and we built in our X-Connect system to make it easy to add a compatible ACID front light just by plugging it in. And, with Size Split, it's simple to find the perfect fit for you.
Specifications
FRAME
Material: Aluminium Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost148, Fully Integrated Battery, Advanced Internal Cable Routing, 1.5 Headtube, Kickstand/Fender/Carrier Mounting Points
SUSPENSION
Fork: SR Suntour XCM34 NLO Coil, Tapered, 15x110mm, 120mm (27.5: 100mm)
Headset: ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface
E-BIKE SYSTEM
Drive Unit: Bosch Drive Unit Performance Line 75Nm (BDU34), 32kph
Battery: Bosch PowerTube 600
Charger: Bosch 2A
Display: Bosch Purion 200 with Integrated Display
COCKPIT
Stem: CUBE Performance Stem E-MTB 35, FPI-Link
Handlebar: CUBE Rise Trail Bar 35
Grips: ACID Hybrid Perform
DRIVETRAIN & BRAKES
Rear Derailleur: Shimano Cues RD-U4000-GS, 9-Speed
Chain Guide: Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Shifters: Shimano Cues SL-U4010- Rapidfire-Plus
Brake System: Shimano BR-MT200, Hydr. Disc Brake (180/180)
Crankset: ACID MTB Hybrid Pro, 38T
Cassette: Shimano Cues CS-LG300, 11-46T
Chain: KMC eGlide
WHEELS
Wheelset: ACID Pro 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
Tyres: Schwalbe Smart Sam, Active, 2.6
FINISHING KIT
Saddle: ACID Sequence 160
Seat Post: CUBE Performance Post, 31.6mm
Pedals: ACID PP Trekking
WEIGHT & MISC
Weight: 24,8 kg
Maximum System Weight: 150 kg
Maximum Rider Weight: 120 kg
Colour: indigoblue´n´reflex
