Description

We like to make bikes that are both beautiful and practical. The Stereo Hybrid 120 Allroad' s included mudguards, luggage carrier, lights and kickstand speak for themselves: you've everything you need. Our Modular Battery System protects the high-capacity Bosch battery from dust and water. The four-bar suspension system, refined over many years, keeps you isolated from bumps and vibration, while Comfort Geometry and the precise steering ensured by a Boost 148 rear end and 1.5in head tube means you can just enjoy the ride. And, as you'd expect, our SizeSplit system means every rider can find their perfect fit, with zero compromise.

Specifications

FRAME
Material: Aluminum Superlite
Features: Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, Fully Integrated Battery, Advanced Internal Cable Routing

SIZE
Size Split: 27.5: S (16") // 29: M (18"), L (20"), XL (22")

SUSPENSION
Fork: Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm
Shock: Fox Float DPS EVOL, 185x55mm (27.5: 165x45mm), Open/Medium/Firm Mode, Trunnion Mount
Shock Hardware: Top: 54mm Trunnion Mount, Bottom: 30x8mm

E-BIKE SYSTEM
Drive Unit: Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
Remote: Bosch LED Remote
Battery: Bosch PowerTube 750
Display: Bosch Purion 200
Charger: Bosch 2A

DRIVETRAIN & BRAKES
Brake System: Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
Rear Derailleur: Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Shifters: Shimano Deore SL-M6100, Rapidfire-Plus
Crankset: ACID E-Crank, 38T, 170mm
Cassette: Shimano Deore CS-M6100, 10-51T
Chain: Shimano CN-M6100

COCKPIT
Headset: ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120?, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
Stem: CUBE Performance Stem E-MTB, 31.8mm
Handlebar: Newmen Evolution SL 318.25, 760mm
Grips: ACID Hybrid Perform

WHEELS
Rims: CUBE EX30, 32H, Disc, Tubeless Ready
Front Hub: Shimano HB-MT400-B, 15mm, Boost, Centerlock
Rear Hub: Shimano FH-MT410-B, 12mm, Boost, Centerlock
Tyres: Schwalbe Smart Sam, Active, 2.6

FINISHING KIT
Saddle: Natural Fit Sequence
Seat Post: CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 30.9mm
Pedals: ACID PP MTB
Front Light: ACID Front Light PRO-E 110, 5-16V, DC
Rear Light: ACID Mudguard Rear Light PRO-E, 12V, DC
Kickstand: ACID FM Pure Kickstand
Mudguards: ACID 75
Bell: Knog Oi
Carrier: ACID Semi-Integrated Carrier, ACID RILink Adapter Compatible
Lock: Abus Art.Nr. 64293

WEIGHT
Weight: 27.4 kg
Structural Weight: 160 kg
Maximum Rider Weight: 110 kg
Bike Weight and Rider Weight: 135 kg
